• SIT TAPER LOCK BUSHING is designed to give the following:
• 1. Perfect assembly
• 2. rapid dismantling of the pulley and other transmission equipment
• 3. No special tools requirement except hexagonal key
•
• The large range of finished bores available ensures that an immediate assembly can be made thus avoiding costly factory down-time.
•
• Here are the dimensions of Taper Bushing with type 4040 (100.100)
• - Bore : we provide taper bushing with minimal bore 40 mm; for the max bore you can look at the number writen after "BC" in every product name.
• for example, BC100100F100 (4040X100MM), so the max bore is 100 mm.
• - Width : the numbers writen in every product name before "F" is width size.
• for example, BC100100F100 (4040X100MM), so the width is 100 mm.
• - Bore size : look at the last number in every product name.
• for example, BC100100F100, so the bore size is 100.

Dimensions in milimeters:

Keyways are British Standard Metric B S 4235. Part 1: 1972 DIN 6885 and conform to ISO recomendations with the exception of those marked, which are shallower. Where a key is to be used it should be parallel and side fitting, with top clearance. Depth of keyway is measured at the CENTRE

Dimensions in milimeters:

Keyways are British Standard Metric B S 4235. Part 1: 1972 DIN 6885 and conform to ISO recomendations with the exception of those marked, which are shallower. Where a key is to be used it should be parallel and side fitting, with top clearance. Depth of keyway is measured at the CENTRE
