• SIT TAPER LOCK BUSHING is designed to give the following:
• 1. Perfect assembly
• 2. rapid dismantling of the pulley and other transmission equipment
• 3. No special tools requirement except hexagonal key
•
• The large range of finished bores available ensures that an immediate assembly can be made thus avoiding costly factory down-time.
•
•
• Here are the dimensions of Taper Bushing with type 1610 (40.25)
• - Bore : we provide taper bushing with minimal bore 12 mm and 3/8 inches; for the max bore you can look at the number writen after "BC" in every product name.
• for example, BC4025F12 (1610X12MM), so the max bore is 40 mm.
• - Width : the numbers writen in every product name before "F" is width size.
• for example, BC4025F12 (1610X12MM), so the width is 25 mm.
• - Bore size : look at the last number in every product name.
• for example, BC4025F12, so the bore size is 12.

• Type of belt : 5 M
• Pitch :  5 mm
• Pitch diameter : 237.59 mm
• Outside diameter + flange : -
• Teeth : 150
• Type of bush : 2012
• Belt width : 15 mm
• Type of pulley :15
• Material : Cast iron
• Flange : Without flanges

No description for this product yet.

No description for this product yet.

No description for this product yet.

No description for this product yet.

• TRASCO flexible couplings is the flexible and omocinetic coupling that assures the best performance in relation to the physical space occupied in its class. It has a very compact design and allows safe power transmision by absorbing peak loads and torsional vibrations.
•
• Product detail
• Outside diameter : 135 mm
• Max bore for hub type A : 65 mm
• Max bore for hub type B : 75 mm
• Material : Cast iron grade GG25
• Color of spider : Red
• Shore of spider : 98 Sh.A
• Compound of spider : Polyurethane
• Admissible Temperature [°C] of spider : the rang is between -30 and +90°C
•
• Approved according to EC standard ATEX 94/9/EC.

• TORQUE-FLEX® - Narrow "XP" high performance belts are manufactured in accordance with European standards ISO 4184, DIN 7753 and are approved by API (American Petroleum Institute).
•
• The belt structure guarantees high transmittable power while the moulded cog profile provides higher flexibility with small diameters pulleys.
•
• Here are the product dimension :
• - Section : XPZ
• - Belt width : 10 mm
• - High belt : 8 mm
• - Datum length : refer to the last number in every product names, for example : CSXPZ512, so the datum length is 512 mm,

• TORQUE-FLEX® - Classical high performance belts are manufactured in accordance with European standards ISO 4184 and DIN 7753.
•
• Designed for operating at high speeds over small diameter pulleys and short center distances. Also for use in multiple v-belt drives where high shock load and heavy-duty loads are encountered; compressors, industrial fans, textile machinery, woodworking machinery, and construction equipment.
•
• Here are the product dimensions :
• - Section : BX
• - Belt width : 17 mm
• - High belt : 11 mm
• - Inside length : refer to the last number in every product names, for example : CTBX100, so the inside length is 100 inches.

• SIT - WEDGE belts are manufactured in accordance with American standards RMA and MPTA. Available in two different ranges :
• - MC range (Raw Edge and Moulded Cog) : up to 2995 mm length
• - E range (Envelope) : over 2995 mm length.
•
• The product size
• For example, CW3V1000
• - 3V = Section, with belt width 10 mm and high belt 8 mm
• - 1000 = Effective length x 10 (inches)

• SIT EXCELITE® ES - Narrow V-Belts are manufactured in accordance with ISO 4184 -and DIN 7753.
•
• Our high performance narrow v-belts have been specially designed for heavy-duty applications to deliver up to 50% more power than classical v-belts. Can be used in a wide range of industrial and agricultural fields such as compressor, fans, pumps and the other heavy-duty equipment.
•
• Here are the product dimension :
• - Belt width : 13 mm
• - High belt : 10 mm
• - Inside length : refer to the last number in every product names, for example : CLSPA1000, so the inside length is 1000 mm.

No description for this product yet.

No description for this product yet.

• The CLASSICA® synchronous belt, being designed with imperial pitch, is a valid and economical altenative solution in low/medium torque transmission systems.
•
• Reduced elongation, no need of lubrication and low wearing makes this belt an economic and reliable option.
•
• How to measure the size of a product :
• For example, CD210L075
• - 210 = pitch length x 10 (inches)
• - L = pitch
• - 75 = belt width x 100 (inches)

• The CLASSICA® synchronous belt, being designed with imperial pitch, is a valid and economical altenative solution in low/medium torque transmission systems.
•
• Reduced elongation, no need of lubrication and low wearing makes this belt an economic and reliable option.
•
• How to measure the size of a product :
• For example, CD210L075
• - 210 = pitch length x 10 (inches)
• - L = pitch
• - 75 = belt width x 100 (inches)

No description for this product yet.

No description for this product yet.

• TOP DRIVE® HTD belt is an evolution of standard positive drive belts. The tooth shape is the HTD profile according to ISO 13050.
•
• This profile has been used for many years in a wide range of applications and it is well known for its outstanding performances. Power transmission is much higher compared to the classic inch trapezodial profile.
•
• The circular-arc tooth provides superior tooth jump resistance and provides a smooth tooth engagement. The noise level is remarkably reduced if compared to the classic trapezodial belts.
•
• How to measure the size of a product :
• For example, CHD1064-8M20
• - 1640 = pitch length (mm)
• - 8M = pitch
• - 20 = belt width (mm)

No description for this product yet.

No description for this product yet.

• Type of belt : S 14 M
• Pitch :  14 mm
• Pitch diameter : 353.71 mm
• Outside diameter + flange : -
• Teeth : 80
• Belt width : refer to the last number in product name (for example, ST80-S14M115, so, the belt width is 115mm)
• Type of pulley : 11
• Material : Cast iron
• Flange : Without flanges

• SIT-LOCK® locking assembly unit consists of four pieces with two inside double-one rings joined through a set of tightening screws. It is recomended for medium torques. Although it is not self centering, it can be easily assembled and diassembled.
•
• Here are the dimensions of product :
• Inner Diameter : 420 mm
• Outside Diameter : 515 mm
• High : 90 mm
• Screws : 40
• Type of Screws : M22

• Locking assembly with single taper design. Provides good concentricity and self centering.
• It is recommended for medium torques and is self-centring.
• The flange design prevents axial movement during installation.
•
• For the dimension of the product, please download the catalog in the document section
